Fully Automatic SMT Wave Solder Out Feed Conveyer for Wave Soldering Machine

Name: Fully Automatic SMT Wave Solder Out Feed Conveyer for Wave Soldering Machine
Brand: YUSH
Price: 7 USD

Wholesale Fully Automatic SMT Wave Solder Out Feed Conveyer for Wave Soldering Machine from china suppliers

Place of Origin : Guangdong, China

Brand Name : YUSH

MOQ : 1 set

Price : $7,000-8,000 / set

Weight : 48Kg

Voltage : 220V

Machine Type : Conveyor

Model : YSL-400

Dimensions : 1200*490*1200(mm)

PCB width : 0-400(mm)

PCB direction : L-R

Conveyor speed : 0-4000(mm)/Min

Motor : 1P AC220V 50/60HZ 15W

Power supply : 1P AC220V 50/60HZ

Conveyor Height : 750-1200mm(adjustable)

Belt Material : ESD Belt

Conveyor length : 400±800(mm)

Core components : Motor, Pump

PCB angle : 6-7°

Contact Now

Fully Automatic SMT Wave Solder Out Feed Conveyer

This fully automatic conveyor system is designed to unload PCBs or pallets from wave soldering machines, providing efficient and reliable material handling for SMT production lines.

Key Features

Unloads PCBs or pallets from wave soldering machines at 6-7° angle
Adjustable transmission speed, transfer height, and track angle
Optional cooling fan installation for PCB and component protection
Special ESD belt and track design for smooth transmission and stable operation

Fully Automatic SMT Wave Solder Out Feed Conveyer for Wave Soldering Machine

Technical Specifications

Model	YS-400
Dimensions (L×W×H)	1200 × 490 × 1200 (mm)
PCB Width	0-400 (mm)
PCB Direction	L-R
Conveyor Speed	0-4000 (mm)/Min
Motor	1P AC220V 50/60HZ 15W
Power Supply	1P AC220V 50/60HZ
Conveyor Height	750-1200mm (adjustable)
Belt Material	ESD Belt
Conveyor Length	400±800 (mm)
Weight	Approx. 48Kg
